7.62x51MM ASG M650
The 7.62x51MM ASG M650 is an advanced armor-piercing cartridge utilizing a tungsten carbide core to achieve extreme penetration against heavy body armor, concrete barriers, and light armored vehicles. As illustrated in the technical simulation, it delivers devastating terminal energy at long distances, effortlessly perforating a 7 mm steel plate from 500 meters away at a velocity of 910 m/s.
|
|
|
|
7.62x51MM ASG M650 |
|
|
|
|
|
DESCRIPTION |
|
|
This cartridge is intended for use in 7.62x51MM caliber weapons (MAG, US M660, M219, M240, G3, L1A1, FAL, M14 and other) |
|
|
Technical Specifications |
|
|
- The cartridges shall function within the temperature range from - 54°C to + 52 °C. |
|
|
- life of 10 years. |
|
|
- Cartridge dimensions and performance are in accordance with MIL-PRF-32317 standard. |
|
|
TECHNICAL DATA |
|
|
CARTRIDGE |
|
|
Weight |
23,5 g |
|
Length |
max 71,10 mm |
|
Extract force |
min 267 N |
|
Primer |
large rifle primer, noncorrosive, no mercuric, nontoxic |
|
Powder |
double base powder |
|
CASE |
|
|
Type |
7.62 x 51 mm, Boxer |
|
Weight |
approx. 11,2 g |
|
Length |
max 51,18 mm |
|
Material |
Brass CuZn30 |
|
BULLET |
|
|
Type |
FMJ BT AP (Full Metal Jacket Armor Piercing) |
|
Weight |
approx. 8,20 g (126,6 gr) |
|
Length |
max 29 mm |
|
Diameter |
max 7,84 mm |
|
Material |
Jacket: Gilding metal Core: tungsten core + lead/antimony |
|
Ballistic coefficient G1 0.419 |
|
|
PERFORMANCE |
|
|
Velocity V24m |
910 ± 10 m/s |
|
Muzzle energy E24 m |
3395 J |
|
Chamber pressure |
max 3800 bar, EPVAT method of measurement (using 6215 transducer) |
|
Accuracy |
mean radius max 15,20 cm at 550 m |
|
Terminal ballistic |
projectile penetrates 7 mm thick hard steel plate at range of 500 m |
|
|
|
