12.7x108MM ASG HC
The 12.7x108MM ASG HC is a heavy anti-materiel armor-piercing cartridge utilizing a high-density hard core (typically tungsten carbide) engineered to punch through thick structural defenses, fortifications, and armored vehicles. As shown in the technical simulation, it delivers massive kinetic energy at mid-range, completely perforating a massive 25 mm steel plate from a distance of 200 meters at a velocity of 810 m/s.
|
|
|
|
12.7x108MM ASG HC |
|
|
|
|
|
DESCRIPTION |
|
|
This cartridge is intended for use against personnel and armored targets in 12.7x108MM ASG HC weapons at distance 1200 m. |
|
|
Technical Specifications |
|
|
- The cartridges shall function within the temperature range from -40°C to +52°C. |
|
|
- life of 10 years. |
|
|
- Cartridge dimensions are in accordance with C.I.P. specifications (REV 02-05-15). |
|
|
TECHNICAL DATA |
|
|
CARTRIDGE |
|
|
Weight |
134 g |
|
Length |
max 147 mm |
|
Extract force |
2450 ± 5400N |
|
Primer |
large rifle 12.7/3 DShK, boxer, noncorrosive, no mercuric |
|
Powder |
double base powder |
|
CASE |
|
|
Type |
12,7 x 108, BOXER |
|
Weight |
approx. 68 g |
|
Length |
max 108 mm |
|
Material |
Brass CuZn30 |
|
BULLET |
|
|
Type |
FMJ BT AP (Full Metal Jacket Armor Piercing) |
|
Weight |
approx. 51,3 g (792 gr) |
|
Length |
max 56,1 mm |
|
Diameter |
max 13,01 mm |
|
Material |
Jacket: Gilding metal Core: tungsten core + lead/antimony |
|
Ballistic coefficient G1 0.930 (ICAO) |
|
|
PERFORMANCE |
|
|
Velocity V25m |
810 ± 825 m/s |
|
Muzzle energy E25m |
17037 J |
|
Chamber pressure |
max 3040 bar, crusher method of measurement |
|
Accuracy |
max mean radius 200 mm at 300 m |
|
Terminal ballistic |
projectile penetrate 20 mm thick hard steel plate with 90% probability -at range of 100 m from muzzle |
|
|
|
