6.5x39MM ASG HC
6.5x39MM ASG HC is a military armor-piercing cartridge engineered with a high-density hard core. It delivers exceptional long-range accuracy and energy retention up to 800 meters. This specialized round is designed to defeat body armor and light armored steel plates.
|
|
|
|
6.5x39MM ASG HC |
|
|
|
|
|
DESCRIPTION |
|
|
This cartridge is intended for use against personnel and light armored targets in 6.5x39MM ASG caliber weapons at distance 800 m |
|
|
Technical Specifications |
|
|
- The cartridges shall function within the temperature range from - 54 °C to + 52 °C |
|
|
- Life 10 years |
|
|
- Cartridge dimensions are in accordance with Serbian military defense standard |
|
|
TECHNICAL DATA |
|
|
CARTRIDGE |
|
|
Weight |
17.8 g |
|
Length |
max 57 mm |
|
Extract force |
min 250 N |
|
Primer |
Small rifle primer, non-corrosive, mercuric, non-toxic |
|
Powder |
Double base powder |
|
CASE |
|
|
Type |
6.5 x 39 mm, Boxer |
|
Weight |
approx. 7.9 g |
|
Length |
max 38.60 mm |
|
Material |
Brass CuZn30 |
|
BULLET |
|
|
Type |
FMJ BT AP (Full Metal Jacket Armor Piercing) |
|
Weight |
approx. 7.80 g (120 g) |
|
Length |
max 30.2 mm |
|
Diameter |
max 6.71 mm |
|
Material |
Jacket: Gilding metal, Core: Tungsten core |
|
Ballistic coefficient G1 0.540 |
|
|
PERFORMANCE |
|
|
Velocity V, 25 m |
740 ± 10 m/s |
|
Muzzle energy E25 m |
2135 J |
|
Chamber pressure |
Max 3650 bar, EPVAT method of measurement |
|
Accuracy |
Max extreme spread (5 shots) 220 mm at 300 m from muzzle |
|
Terminal ballistic |
Projectile penetrates 8 mm thick hard steel plate with 90% probability at a range of 100 m from muzzle |
|
Test barrel length |
415 m |
|
|
|
