7.62x54 MM ASG HC
The 7.62x54 MM ASG HC is a full-powered, rimmed military armor-piercing cartridge utilizing a high-density hardened core designed to defeat reinforced ballistic armor and light armored targets. As shown in the technical simulation, it retains substantial kinetic energy at mid-range, completely perforating a 10 mm steel plate from a distance of 200 meters at a velocity of 820 m/s.
|
|
|
|
7.62x54 MM ASG HC |
|
|
|
|
|
DESCRIPTION |
|
|
This cartridge is intended for use against personnel and light armored targets in 7.62x54 MM caliber weapons at distance 800 m |
|
|
Technical Specifications |
|
|
- The cartridges shall function within the temperature range from - 54°C to + 52 °C. |
|
|
- life of 10 years. |
|
|
- Cartridge dimensions and performance are in accordance with Serbian military defense standard. |
|
|
TECHNICAL DATA |
|
|
CARTRIDGE |
|
|
Weight |
26,0 g |
|
Length |
max 77,16 mm |
|
Extract force |
min 600 N |
|
Primer |
large rifle, berdan 6,55-DTN, primer, noncorrosive, no mercuric |
|
Powder |
double base powder |
|
CASE |
|
|
Type |
7.62 x 54 mm, berdan |
|
Weight |
approx. 9,6 g |
|
Length |
max 53,72 mm |
|
Material |
Brass CuZn30 |
|
BULLET |
|
|
Type |
FMJ BT AP (Full Metal Jacket Armor Piercing) |
|
Weight |
approx. 11,90 g (184 gr) |
|
Length |
max 33,3 mm |
|
Diameter |
max 7,92 mm |
|
Material |
Jacket: Gilding metal Core: tungsten core + lead/antimony |
|
Ballistic coefficient G1 0.544 |
|
|
PERFORMANCE |
|
|
Velocity V25m |
820 ± 10 m/s |
|
Muzzle energy E25m |
4000 J |
|
Chamber pressure |
max 2900 bar, C.I.P crusher method of measurement max 3500 bar, C.I.P transducer method of measurement |
|
Accuracy |
max extreme spread (5 shots) 200 mm at 300 m form muzzle |
|
Terminal ballistic |
projectile penetrate 10 mm thick hard steel plate with 90 % probability - at range of 200 m |
|
|
|
