DRONE - A
The DRONE - A is a small unmanned aerial system designed with advanced tactical capabilities. It features a lightweight delta wing design that allows it to be fast and highly maneuverable in field missions. It is used for reconnaissance, surveillance, and data collection via a portable ground control station, equipped with cameras and sensors to provide accurate information in military or security environments.
|
|
||
|
DRONE / A |
||
|
|
||
|
- The Jet is a multi-mission loiter munition designed for battle eld deployment quick to put into service, intuitive to program and operate. We have dedicated substantial resources to developing an extremely secure system, equipped with three levels of safety. |
||
|
- The cost-effectiveness is unmatched compared to conventional anti-tank missiles: the drone can fly up to 100 km with autonomous guidance and low noise, thanks to its electric propulsion. |
||
|
|
||
|
DESCRIPTION |
||
|
The drone a munition (also known as a kamikaze or suicide drone), it is designed for rapid battlefield deployment and cost-effective precision strikes. |
||
|
Key Specifications |
||
|
Body armor is rated by the National Institute of Justice (NIJ) based on the threats it can stop: |
||
|
Design: |
Features a distinctive delta-wing configuration with winglets, closely resembling the Iranian Shahed-136 but in a more compact size. |
|
|
Propulsion: |
Uses an electric motor with a rear-mounted pusher propeller, which provides a quieter flight profile compared to gasoline-powered drones. |
|
|
Takeoff: |
Employs an autonomous takeoff method assisted by two small rocket boosters on a zero-length twin-rail framework. |
|
|
Flight Performance: |
||
|
Speed: |
Cruising speed of 120 km/h, with a maximum speed of 250 km/h. |
|
|
Range: |
Maximum range is approximately 100 km. |
|
|
Endurance: |
Can remain airborne for 60 to 120 minutes. |
|
|
Payload: |
Typically equipped with a 5 kg warhead, which can be a shaped charge (anti-tank) or thermobaric variant. |
|
|
Operational Features |
||
|
controlled through a portable ground station (that provides a real-time video feed from a 3-axis stabilized camera. This allows operators to identify and confirm targets manually before initiating a strike. While primarily intended for attack missions, it can also be configured for reconnaissance, surveillance, and intelligence gathering. |
||
|
|
||
|
MAIN TECHNICAL PARAMETERES |
||
|
GROUND CONTROL STATION |
||
|
Mission planning |
||
|
Dual monitor high brilliant |
||
|
Full hardware joystick control |
||
|
Safety Switch |
||
|
Output for external monitors |
||
|
Up to 4 hrs. battery |
||
|
Up to 40 km Video stream |
||
|
2 Kg Antitank and Armored Vehicle, penetration up to 400 mm thickness, Electronical Safety activation Fuse The system is very quick to be ready for takeoff, which happens directly from thereof of the transport case thanks to a rocket engine. |
||
|
Wingspan |
1 700 mm |
|
|
Operational range |
up to 100 km |
|
|
Length |
1 700 mm |
|
|
Max Endurance |
60 min |
|
|
MTOW |
10 kg |
|
|
Takeoff |
Rocket motor |
|
|
Warhead |
2 kg Antitank |
|
|
Max Speed |
300 km/h |
|
|
Cruise Speed |
100 km/h |
|
|
|
||
